GEYA Solid State Relay DC-DC Single Phase SSR 100A Without Cover (DC Control DC,100A)
4.2 (108 items)
Limited Time Sale$12.90 cheaper than the new price!!
Free cash-on-delivery fees for purchases over $99
Product details
| Management number | 218082317 | Release Date | 2026/05/03 | List Price | $8.60 | Model Number | 218082317 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
- Solid State Relay (SSR)is industrial control appliance that uses power semiconductor devices for the main control part, compare with traditional magnetic contact industrial controllers, it is a higher-powered, intelligent, digital, systematic, and green development.
- Wide input voltage range, small control current, samller or equal to 25mA;The photoelectric isolation between the input and output circuits, the insulation withstand voltage is 2500V.
- Fast switching, zero-voltage turn-on, zero-current turn-off, low radio frequency interference;The built-in resistance-capacitance absorption protects the product from the impact of the instantaneous current.
- When selecting relays, please pay special attention to the working current and ambient temperature of the load. When the load is working, it is necessary to add enough radiator or take other effective radiating measures.The heat generated by the relay needs to be dissipated through the relay metal base. When installing, please pay attention to the tight cooperation between the relay and the radiator, the installation should be firm and the joint surface should be coated with thermal grease.
- When the output terminal and the load line are loosely connected, the product will be burnt due to the heat generated during power-on. The followings are the recommended screw installations for product wiring: M4 screw installation with a torque of 0.98~1.37N.m, M3 screw installation torque of 0.58~0.98 N.m, excessive torque will damage the relay.
| Brand Name | GEYA |
|---|---|
| Part Number | GSR1-1-100DD |
| Manufacturer | ZHEJIANG GEYA ELECTRICAL CO.,LTD |
| Mounting Type | Surface Mount |
| Current Rating | 100 Amps |
| Operation Mode | Automatic |
